LM5070 Series
Manufacturer: Texas Instruments
Beta
⌘K
POWER OVER ETHERNET PD CONTROLLER 1.8V 75V 13W 16-PIN TSSOP
| Part | Standards | Package Name | Internal Switch(s) | Auxiliary Sense | Number of Channels | Mounting Type | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Operating Temperature (Max) | Operating Temperature (Min) | Package Length | Package Width | Type | Board Type | Power - Output | Supplied Contents | Total Output Count | Output Type | Isolated Output Count | Regulator Topology | Voltage - Input (Minimum) | Voltage - Input (Maximum) | Main Purpose | Voltage - Output | Utilized IC / Part | Current - Output | Contents | Frequency - Switching | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 802.3af (PoE) | 16-TSSOP | Both | No | 1 | Surface Mount | 75 V | 1.8 V | 125 °C | -40 °C | 0.173 in | 4.4 mm | Controller (PD) DC/DC | ||||||||||||||||
Texas Instruments | 802.3af (PoE) | 16-TSSOP | Both | No | 1 | Surface Mount | 75 V | 1.8 V | 125 °C | -40 °C | 0.173 in | 4.4 mm | Controller (PD) DC/DC | ||||||||||||||||
Texas Instruments | 802.3af (PoE) | 16-TSSOP | Both | No | 1 | Surface Mount | 75 V | 1.8 V | 125 °C | -40 °C | 0.173 in | 4.4 mm | Controller (PD) DC/DC | ||||||||||||||||
 Texas Instruments | 802.3af (PoE) | 16-TSSOP | Both | No | 1 | Surface Mount | 75 V | 1.8 V | 125 °C | -40 °C | 0.173 in | 4.4 mm | Controller (PD) DC/DC | ||||||||||||||||
 Texas Instruments | Fully Populated | 10.89 W | Board(s) | 1 | Isolated | 1 | Flyback | 32 V | 57 V | Power Over Ethernet Special Purpose DC/DC | 3.3 V | LM5070 | 3.3 A | Board | 250 kHz | ||||||||||||||
 Texas Instruments | Fully Populated | 11.22 W | Board(s) | 1 | Isolated | 1 | Flyback | 38 V | 60 V | Power Over Ethernet Special Purpose DC/DC | 3.3 V | LM5070 | 3.4 A | Board | 250 kHz | ||||||||||||||
 Texas Instruments | 802.3af (PoE) | 16-WSON | Both | No | 1 | Surface Mount | 75 V | 1.8 V | 125 °C | -40 °C | 5 mm | 5 mm | Controller (PD) DC/DC | 16-WFDFN Exposed Pad | |||||||||||||||
Texas Instruments | 802.3af (PoE) | 16-TSSOP | Both | No | 1 | Surface Mount | 75 V | 1.8 V | 125 °C | -40 °C | 0.173 in | 4.4 mm | Controller (PD) DC/DC | ||||||||||||||||
Texas Instruments | 802.3af (PoE) | 16-WSON | Both | No | 1 | Surface Mount | 75 V | 1.8 V | 125 °C | -40 °C | 5 mm | 5 mm | Controller (PD) DC/DC | 16-WFDFN Exposed Pad | |||||||||||||||
Texas Instruments | 802.3af (PoE) | 16-WSON | Both | No | 1 | Surface Mount | 75 V | 1.8 V | 125 °C | -40 °C | 5 mm | 5 mm | Controller (PD) DC/DC | 16-WFDFN Exposed Pad |
