LMP8278 Series
Manufacturer: Texas Instruments
Beta
⌘K
AEC-Q100, -2 TO 40V, SPLIT-STAGE CURRENT SENSE AMPLIFIER W/ IN-LINE FILTER CAPABILITY
| Part | Voltage - Supply Span (Max) | Gain Bandwidth Product | Current - Input Bias | Package Width | Package Name | Package Length | Voltage - Input Offset | Number of Circuits | Mounting Type | Amplifier Type | Current - Supply | Slew Rate | Operating Temperature (Max) | Operating Temperature (Min) | Qualification | Grade | Voltage - Supply Span (Min) | Current - Output / Channel | Supplied Contents | Board Type | Current - Supply (Main IC) | Utilized IC / Part | Voltage - Supply (Single) Maximum | Supply Configuration | Voltage - Supply (Single) Minimum | Channels per IC (Single) | Channels per IC (Type) | Channels per IC (Count) | Contents | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 5.5 V | 90 kHz | 20 pA | 3 mm | 8-TSSOP 8-MSOP 8-VSSOP | 0.118 in | 250 µV | 1 | Surface Mount | Current Sense | 400 µA | 0.7 V/µs | 125 °C | -40 °C | AEC-Q100 | Automotive | 4.5 V | 10 mA | ||||||||||||
 Texas Instruments | Current Sense | 0.7 V/µs | 10 mA | Board(s) | Fully Populated | 0.0004 µA | LMP8278 | 5.5 V | Dual Single | 4.5 V | 1 | Single | 1 | Board | Single-Ended | |||||||||||||||
Texas Instruments | 5.5 V | 90 kHz | 20 pA | 3 mm | 8-TSSOP 8-MSOP 8-VSSOP | 0.118 in | 250 µV | 1 | Surface Mount | Current Sense | 400 µA | 0.7 V/µs | 125 °C | -40 °C | AEC-Q100 | Automotive | 4.5 V | 10 mA | ||||||||||||
Texas Instruments | 5.5 V | 90 kHz | 20 pA | 3 mm | 8-TSSOP 8-MSOP 8-VSSOP | 0.118 in | 250 µV | 1 | Surface Mount | Current Sense | 400 µA | 0.7 V/µs | 125 °C | -40 °C | AEC-Q100 | Automotive | 4.5 V | 10 mA |
