LP38858 Series

Catalog

1.5-A, LOW-VIN (0.98-V), HIGH-ACCURACY, ULTRA-LOW-DROPOUT VOLTAGE REGULATOR

Part	Output Configuration	Control Features	Voltage - Input (Max)	Package Name	Current - Quiescent (Iq)	Current - Output	PSRR (Maximum)	PSRR (Minimum)	Protection Features	Number of Regulators	Current - Supply (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Voltage Dropout (Max)	Output Type	Voltage - Output (Min/Fixed)	Package / Case	Package Leads
Texas Instruments LP38858T-1.2/NOPB	Positive	Soft Start	5.5 V	TO-220-5	8.5 mA	1.5 A	80 dB	65 dB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	1	15 mA	125 °C	-40 °C	Through Hole	0.18 V	Fixed	1.2 V	TO-220-5 Formed Leads
Texas Instruments LP38858S-1.2	Positive	Soft Start	5.5 V	D2PAK TO-263 (DDPAK-5)	8.5 mA	1.5 A	80 dB	65 dB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	1	15 mA	125 °C	-40 °C	Surface Mount	0.18 V	Fixed	1.2 V		5 Leads
Texas Instruments LP38858T-1.2	Positive	Soft Start	5.5 V	TO-220-5	8.5 mA	1.5 A	80 dB	65 dB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	1	15 mA	125 °C	-40 °C	Through Hole	0.18 V	Fixed	1.2 V	TO-220-5 Formed Leads
Texas Instruments LP38858S-1.2/NOPB	Positive	Soft Start	5.5 V	D2PAK TO-263 (DDPAK-5)	8.5 mA	1.5 A	80 dB	65 dB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	1	15 mA	125 °C	-40 °C	Surface Mount	0.18 V	Fixed	1.2 V		5 Leads
Texas Instruments LP38858SX-1.2	Positive	Soft Start	5.5 V	D2PAK TO-263 (DDPAK-5)	8.5 mA	1.5 A	80 dB	65 dB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	1	15 mA	125 °C	-40 °C	Surface Mount	0.18 V	Fixed	1.2 V		5 Leads
Texas Instruments LP38858SX-1.2/NOPB	Positive	Soft Start	5.5 V	D2PAK TO-263 (DDPAK-5)	8.5 mA	1.5 A	80 dB	65 dB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	1	15 mA	125 °C	-40 °C	Surface Mount	0.18 V	Fixed	1.2 V		5 Leads
