SN65LVPE501 Series

Catalog

DUAL CHANNEL SINGLE-LANE PCI EXPRESS GEN II REDRIVER

Part	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Applications	Current - Supply	Output	Delay Time	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	Input	Data Rate (Max)	Signal Conditioning	Number of Channels	Package Length	Package Name	Package Width	Mounting Type	Type
Texas Instruments SN65LVPE501RGER	3.6 V	3 V	PCIe	101 mA	CML	280 ps	-40 °C	85 °C	24-VFQFN Exposed Pad	CML	5 Gbps	Input Equalization Output De-Emphasis	2	4 mm	24-VQFN	4 mm	Surface Mount	Buffer ReDriver
Texas Instruments SN65LVPE501RGET	3.6 V	3 V	PCIe	101 mA	CML	280 ps	-40 °C	85 °C	24-VFQFN Exposed Pad	CML	5 Gbps	Input Equalization Output De-Emphasis	2	4 mm	24-VQFN	4 mm	Surface Mount	Buffer ReDriver
