LM20124 Series

Catalog

2.95-5.5V, 4A, CURRENT MODE SYNCHRONOUS BUCK REGULATOR WITH OPTIONAL AUTOMOTIVE GRADE

Part	Voltage - Output (Min/Fixed)	Output Type	Voltage - Input (Max)	Voltage - Input (Min)	Topology	Current - Output	Package Length	Package Name	Package Width	Synchronous Rectifier	Voltage - Output (Max)	Function	Operating Temperature (Max)	Operating Temperature (Min)	Frequency - Switching	Output Configuration	Number of Outputs	Mounting Type
Texas Instruments LM20124MHX/NOPB	0.8 V	Adjustable	5.5 V	2.95 V	Buck	4 A	0.173 in	16-HTSSOP 16-PowerTSSOP	4.4 mm	Yes	4.68 V	Step-Down	125 °C	-40 °C	1 MHz	Positive	1	Surface Mount
Texas Instruments LM20124MH/NOPB	0.8 V	Adjustable	5.5 V	2.95 V	Buck	4 A	0.173 in	16-HTSSOP 16-PowerTSSOP	4.4 mm	Yes	4.68 V	Step-Down	125 °C	-40 °C	1 MHz	Positive	1	Surface Mount
Texas Instruments LM20124MHE/NOPB	0.8 V	Adjustable	5.5 V	2.95 V	Buck	4 A	0.173 in	16-HTSSOP 16-PowerTSSOP	4.4 mm	Yes	4.68 V	Step-Down	125 °C	-40 °C	1 MHz	Positive	1	Surface Mount
Texas Instruments LM20124MHE/NOPB	0.8 V	Adjustable	5.5 V	2.95 V	Buck	4 A	0.173 in	16-HTSSOP 16-PowerTSSOP	4.4 mm	Yes	4.68 V	Step-Down	125 °C	-40 °C	1 MHz	Positive	1	Surface Mount
