LM3886 Series

Catalog

68W, 1 CH, 20-94V SUPPLY STEREO CLASS-AB AMPLIFIER W/ MUTE

Part	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Voltage - Supply Tolerance (Maximum)	Voltage - Supply Tolerance (Minimum)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Load Impedance	Maximum Output Power (per Channel)	Channels	Package / Case	Package Name	Type	Features	Output Type
Texas Instruments LM3886T/NOPB	20 VDC	84 V	42 V	-10 V	85 °C	-20 °C	Through Hole	4 Ohm	68 W	1	TO-220-11 Formed Leads	TO-220-11	Class AB	Mute Short-Circuit and Thermal Protection	1-Channel (Mono)
Texas Instruments LM3886TF	20 VDC	84 V	42 V	-10 V	85 °C	-20 °C	Through Hole	4 Ohm	68 W	1	Formed Leads TO-220-11 Isolated Tab	TO-220-11 Isolated	Class AB	Mute Short-Circuit and Thermal Protection	1-Channel (Mono)
Texas Instruments LM3886TF/NOPB	20 VDC	84 V	42 V	-10 V	85 °C	-20 °C	Through Hole	4 Ohm	68 W	1	Formed Leads TO-220-11 Isolated Tab	TO-220-11 Isolated	Class AB	Mute Short-Circuit and Thermal Protection	1-Channel (Mono)
Texas Instruments LM3886T/NOPB	20 VDC	84 V	42 V	-10 V	85 °C	-20 °C	Through Hole	4 Ohm	68 W	1	TO-220-11 Formed Leads	TO-220-11	Class AB	Mute Short-Circuit and Thermal Protection	1-Channel (Mono)
Texas Instruments LM3886T	20 VDC	84 V	42 V	-10 V	85 °C	-20 °C	Through Hole	4 Ohm	68 W	1	TO-220-11 Formed Leads	TO-220-11	Class AB	Mute Short-Circuit and Thermal Protection	1-Channel (Mono)
