ADS131M08 Series

Catalog

8-CHANNEL OCTAL ADC DELTA-SIGMA 32KSPS 24-BIT SERIAL 32-PIN TQFP T/R

Part	Ratio - ADC	Package Width	Package Name	Package Length	Reference Type	Mounting Type	Package / Case	Number of A/D Converters	Number of Inputs	Data Interface	Architecture	Number of Bits	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Sampling Rate (Per Second)	Features	Operating Temperature (Max)	Operating Temperature (Min)	Configuration	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Input Type	Voltage - Supply, Digital (Range 1) Maximum	Voltage - Supply, Digital (Range 2) Maximum	Voltage - Supply, Digital (Range 2) Minimum	Voltage - Supply, Digital (Range 1) Minimum	Voltage - Supply, Analog (Range 2 Max)	Voltage - Supply, Analog (Range 1 Min)	Voltage - Supply, Analog (Range 1 Max)	Voltage - Supply, Analog (Range 2 Min)
Texas Instruments ADS131M08IPBSR	1	5 mm	32-TQFP	5 mm	Internal	Surface Mount	32-TQFP	8 count	8	SPI	Sigma-Delta	24 bits	2.7 V	3.6 V	32 kHz	PGA Simultaneous Sampling	125 °C	-40 °C	ADC	2.7 V	3.6 V	Differential
Texas Instruments ADS131M08IRSNT	1	4 mm	32-QFN	4 mm	External Internal	Surface Mount	32-WFQFN Exposed Pad	8 count	8	SPI	Sigma-Delta	24 bits	1.65 V	3.6 V	32 kHz	PGA Simultaneous Sampling	125 °C	-40 °C	PGA-ADC	2.4 V	3.6 V	Differential
Texas Instruments ADS131M08IRSNR	8	4 mm	32-QFN	4 mm	External Internal	Surface Mount	32-WFQFN Exposed Pad	8 count	8	SPI	Sigma-Delta	24 bits			32 kHz	PGA Simultaneous Sampling	125 °C	-40 °C	PGA-ADC			Differential	2 V	3.6 V	2.7 V	1.65 V	3.6 V	2.4 V	3.6 V	2.7 V
Texas Instruments ADS131M08IPBS	1	5 mm	32-TQFP	5 mm	Internal	Surface Mount	32-TQFP	8 count	8	SPI	Sigma-Delta	24 bits	2.7 V	3.6 V	32 kHz	PGA Simultaneous Sampling	125 °C	-40 °C	ADC	2.7 V	3.6 V	Differential
