LM2756 Series
Manufacturer: Texas Instruments
Beta
⌘K
EVAL BOARD FOR LM2756
| Part | Output Type | Total Output Count | Non-Isolated Output Count | Supplied Contents | Contents | Features | Current - Output / Channel | Voltage - Input (Minimum) | Voltage - Input (Maximum) | Utilized IC / Part | Operating Temperature (Max) | Operating Temperature (Min) | Topology | Dimming | Type | Package / Case | Applications | Package Name | Number of Outputs | Voltage - Output (Min) | Voltage - Output (Max) | Voltage - Supply (Max) | Internal Switch(s) | Mounting Type | Frequency | Voltage - Supply (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Non-Isolated | 8 | 8 count | Board(s) | Board | Dimmable | 20 mA | 2.7 V | 5.5 V | LM2756 | ||||||||||||||||
 Texas Instruments | 30 mA | 85 °C | -30 °C | Switched Capacitor (Charge Pump) | I2C | DC DC Regulator | 20-WFBGA DSBGA | Backlight | 20-DSBGA | 8 | 2 V | 4 V | 5.5 V | Yes | Surface Mount | 1.3 MHz | 2.7 V | |||||||||
 Texas Instruments | 30 mA | 85 °C | -30 °C | Switched Capacitor (Charge Pump) | I2C | DC DC Regulator | 20-WFBGA DSBGA | Backlight | 20-DSBGA | 8 | 2 V | 4 V | 5.5 V | Yes | Surface Mount | 1.3 MHz | 2.7 V |
