DS100BR210 Series

Catalog

10.3-GBPS LOW POWER 2-CH REDRIVER W/ INPUT EQUALIZATION AND OUTPUT DE-EMPHASIS

Part	Capacitance - Input	Input	Type	Package Length	Package Name	Package Width	Applications	Delay Time	Package / Case	Current - Supply	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Operating Temperature (Min)	Operating Temperature (Max)	Number of Channels	Mounting Type	Data Rate (Max)	Output	Signal Conditioning
Texas Instruments DS100BR210SQ/NOPB	10 pF	CML	Buffer ReDriver	4 mm	24-WQFN	4 mm	SATA	230 ps	24-WFQFN Exposed Pad	50 mA	2.375 V	3.6 V	-40 °C	85 °C	2	Surface Mount	10.3 Gbps	CML	Input Equalization Output De-Emphasis
Texas Instruments DS100BR210SQE/NOPB	10 pF	CML	Buffer ReDriver	4 mm	24-WQFN	4 mm	SATA	230 ps	24-WFQFN Exposed Pad	50 mA	2.375 V	3.6 V	-40 °C	85 °C	2	Surface Mount	10.3 Gbps	CML	Input Equalization Output De-Emphasis
