LM2751 Series

Catalog

IC LED DRV RGLTR PWM 80MA 10WSON

Part	Topology	Voltage - Output	Applications	Package Length	Package Name	Package Width	Dimming	Voltage - Supply (Min)	Number of Outputs	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Package / Case	Type	Voltage - Supply (Max)	Current - Output / Channel	Internal Switch(s)
Texas Instruments LM2751SDX-A	Switched Capacitor (Charge Pump)	5 VDC	Backlight	3 mm	10-WSON	3 mm	PWM	2.8 V	1	85 °C	-40 °C	Surface Mount	10-WFDFN Exposed Pad	DC DC Regulator	5.5 V	80 mA	Yes
Texas Instruments LM2751SDX-B	Switched Capacitor (Charge Pump)	4.5 V	Backlight	3 mm	10-WSON	3 mm	PWM	2.8 V	1	85 °C	-40 °C	Surface Mount	10-WFDFN Exposed Pad	DC DC Regulator	5.5 V	150 mA	Yes
Texas Instruments LM2751SDX-A/NOPB	Switched Capacitor (Charge Pump)	5 VDC	Backlight	3 mm	10-WSON	3 mm	PWM	2.8 V	1	85 °C	-40 °C	Surface Mount	10-WFDFN Exposed Pad	DC DC Regulator	5.5 V	80 mA	Yes
Texas Instruments LM2751SD-A	Switched Capacitor (Charge Pump)	5 VDC	Backlight	3 mm	10-WSON	3 mm	PWM	2.8 V	1	85 °C	-40 °C	Surface Mount	10-WFDFN Exposed Pad	DC DC Regulator	5.5 V	80 mA	Yes
Texas Instruments LM2751SD-B/NOPB	Switched Capacitor (Charge Pump)	4.5 V	Backlight	3 mm	10-WSON	3 mm	PWM	2.8 V	1	85 °C	-40 °C	Surface Mount	10-WFDFN Exposed Pad	DC DC Regulator	5.5 V	150 mA	Yes
Texas Instruments LM2751SD-A	Switched Capacitor (Charge Pump)	5 VDC	Backlight	3 mm	10-WSON	3 mm	PWM	2.8 V	1	85 °C	-40 °C	Surface Mount	10-WFDFN Exposed Pad	DC DC Regulator	5.5 V	80 mA	Yes
Texas Instruments LM2751SDX-B/NOPB	Switched Capacitor (Charge Pump)	4.5 V	Backlight	3 mm	10-WSON	3 mm	PWM	2.8 V	1	85 °C	-40 °C	Surface Mount	10-WFDFN Exposed Pad	DC DC Regulator	5.5 V	150 mA	Yes
Texas Instruments LM2751SD-A/NOPB	Switched Capacitor (Charge Pump)	5 VDC	Backlight	3 mm	10-WSON	3 mm	PWM	2.8 V	1	85 °C	-40 °C	Surface Mount	10-WFDFN Exposed Pad	DC DC Regulator	5.5 V	80 mA	Yes
