LM4666 Series
Manufacturer: Texas Instruments
Beta
⌘K
1.2-W, STEREO, ANALOG INPUT CLASS-D AUDIO AMP WITH SELECTABLE GAIN
| Part | Features | Type | Operating Temperature (Max) | Operating Temperature (Min) | Load Impedance | Channels | Maximum Output Power (per Channel) | Mounting Type | Output Type | Package Name | Package Width | Package Length | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Package / Case | Contents | Utilized IC / Part | Amplifier Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Depop Differential Inputs Short-Circuit Protection Shutdown | Class D | 85 °C | -40 °C | 8 Ohm | 2 | 1.2 W | Surface Mount | 2-Channel (Stereo) | 14-WSON | 3 mm | 4 mm | 5.5 V | 2.8 V | 14-WFDFN Exposed Pad | |||
 Texas Instruments | 8 Ohm | 2 | 1.2 W | 2-Channel (Stereo) | 5.5 V | 2.8 V | Board | LM4666 | Class D | |||||||||
Texas Instruments | Depop Differential Inputs Short-Circuit Protection Shutdown | Class D | 85 °C | -40 °C | 8 Ohm | 2 | 1.2 W | Surface Mount | 2-Channel (Stereo) | 14-WSON | 3 mm | 4 mm | 5.5 V | 2.8 V | 14-WFDFN Exposed Pad |
