LP3879 Series

Catalog

IC REG LIN 1V 800MA 8SO POWERPAD

Part	Package Width	Package Name	Package Length	Output Configuration	Output Type	Current - Quiescent (Iq)	Protection Features	Operating Temperature (Max)	Operating Temperature (Min)	Current - Supply (Max)	Number of Regulators	Current - Output	PSRR	Voltage - Input (Max)	Control Features	Mounting Type	Voltage - Output (Min/Fixed)	Package / Case
Texas Instruments LP3879MRX-1.0	3.9 mm	8-PowerSOIC 8-SO PowerPad	0.154 in	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1 V
Texas Instruments LP3879MRX-1.2/NOPB	3.9 mm	8-PowerSOIC 8-SO PowerPad	0.154 in	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1.2 V
Texas Instruments LP3879SDX-1.2/NOPB	4 mm	8-WSON	4 mm	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1.2 V	8-WDFN Exposed Pad
Texas Instruments LP3879SD-1.0	4 mm	8-WSON	4 mm	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1 V	8-WDFN Exposed Pad
Texas Instruments LP3879MR-1.0	3.9 mm	8-PowerSOIC 8-SO PowerPad	0.154 in	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1 V
Texas Instruments LP3879MRX-1.0/NOPB	3.9 mm	8-PowerSOIC 8-SO PowerPad	0.154 in	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1 V
Texas Instruments LP3879MR-1.0/NOPB	3.9 mm	8-PowerSOIC 8-SO PowerPad	0.154 in	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1 V
Texas Instruments LP3879SD-1.0	4 mm	8-WSON	4 mm	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1 V	8-WDFN Exposed Pad
Texas Instruments LP3879SD-1.0/NOPB	4 mm	8-WSON	4 mm	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1 V	8-WDFN Exposed Pad
Texas Instruments LP3879SD-1.2/NOPB	4 mm	8-WSON	4 mm	Positive	Fixed	1.4 mA	Over Current Over Temperature Short Circuit	125 °C	-40 °C	2.2 mA	1	800 mA	60 dB	6 V	Enable	Surface Mount	1.2 V	8-WDFN Exposed Pad
