SN74AUP1G07 Series

Single 0.8-V to 3.6-V low power buffer with open-drain outputs

Catalog

Single 0.8-V to 3.6-V low power buffer with open-drain outputs

Part	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Logic Type	Output Type	Package Name	Number of Elements	Current - Output Low	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Number of Bits per Element	Package Length	Package Width
Texas Instruments SN74AUP1G07DCKT	5-TSSOP SC-70-5 SOT-353	85 °C	-40 °C	Surface Mount	Buffer Non-Inverting	Open Drain	SC-70-5	1	4 mA	0.8 V	3.6 V	1 bits
Texas Instruments SN74AUP1G07DCKRE4	5-TSSOP SC-70-5 SOT-353	85 °C	-40 °C	Surface Mount	Buffer Non-Inverting	Open Drain	SC-70-5	1	4 mA	0.8 V	3.6 V	1 bits
Texas Instruments SN74AUP1G07DSF2	6-XFDFN	85 °C	-40 °C	Surface Mount	Buffer Non-Inverting	Open Drain	6-SON	1	4 mA	0.8 V	3.6 V	1 bits	1 mm	1 mm
Texas Instruments SN74AUP1G07YZPR	5-XFBGA DSBGA	85 °C	-40 °C	Surface Mount	Buffer Non-Inverting	Open Drain	5-DSBGA	1	4 mA	0.8 V	3.6 V	1 bits	1.4 mm	0.9 mm
Texas Instruments SN74AUP1G07DSFR	6-XFDFN	85 °C	-40 °C	Surface Mount	Buffer Non-Inverting	Open Drain	6-SON	1	4 mA	0.8 V	3.6 V	1 bits	1 mm	1 mm
Texas Instruments SN74AUP1G07YFPR	4-XFBGA DSBGA	85 °C	-40 °C	Surface Mount	Buffer Non-Inverting	Open Drain	4-DSBGA	1	4 mA	0.8 V	3.6 V	1 bits
Texas Instruments SN74AUP1G07DPWR	4-XFDFN Exposed Pad	85 °C	-40 °C	Surface Mount	Buffer Non-Inverting	Open Drain	4-X2SON	1	4 mA	0.8 V	3.6 V	1 bits	0.8 mm	0.8 mm
Texas Instruments SN74AUP1G07DRLR	SOT-553	85 °C	-40 °C	Surface Mount	Buffer Non-Inverting	Open Drain	SOT-5	1	4 mA	0.8 V	3.6 V	1 bits

Catalog

Single 0.8-V to 3.6-V low power buffer with open-drain outputs

Description

The SN74AUP1G07 device is a single buffer gate with open drain output that operates from 0.8 V to 3.6 V. The SN74AUP1G07 device is a single buffer gate with open drain output that operates from 0.8 V to 3.6 V.
