ADS112U04 Series

Catalog

16-BIT, 2-KSPS, 4-CH, LOW-POWER, SMALL-SIZE DELTA-SIGMA ADC W/ PGA, VREF, 2X IDACS & UART INTERFACE

Part	Voltage - Supply, Analog (Typical)	Voltage - Supply, Analog (Tolerance)	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Sampling Rate (Per Second)	Configuration	Input Type	Number of Bits	Features	Number of A/D Converters	Architecture	Operating Temperature (Max)	Operating Temperature (Min)	Reference Type	Number of Inputs	Package Name	Package Length	Package Width	Mounting Type	Data Interface	Voltage - Supply, Digital (Max)	Voltage - Supply, Digital (Min)	Package / Case
Texas Instruments ADS112U04IPWR	2.5 V	2.5 V	5.5 V	2.3 V	2000 Hz	MUX-PGA-ADC	Differential Pseudo-Differential Single Ended	16 bits	PGA Temperature Sensor	1 count	Sigma-Delta	125 °C	-40 °C	External Internal	4	16-TSSOP	0.173 in	4.4 mm	Surface Mount	UART	5.5 V	2.3 V
Texas Instruments ADS112U04IPW	2.5 V	2.5 V	5.5 V	2.3 V	2000 Hz	MUX-PGA-ADC	Differential Pseudo-Differential Single Ended	16 bits	PGA Temperature Sensor	1 count	Sigma-Delta	125 °C	-40 °C	External Internal	4	16-TSSOP	0.173 in	4.4 mm	Surface Mount	UART	5.5 V	2.3 V
Texas Instruments ADS112U04IRTER			5.5 V	2.3 V	2000 Hz	MUX-PGA-ADC	Differential Single Ended	16 bits	PGA Temperature Sensor	1 count	Sigma-Delta	125 °C	-40 °C	External Internal	4	16-WQFN	3 mm	3 mm	Surface Mount	UART	5.5 V	2.3 V	16-WFQFN Exposed Pad
Texas Instruments ADS112U04IRTET			5.5 V	2.3 V	2000 Hz	MUX-PGA-ADC	Differential Single Ended	16 bits	PGA Temperature Sensor	1 count	Sigma-Delta	125 °C	-40 °C	External Internal	4	16-WQFN	3 mm	3 mm	Surface Mount	UART	5.5 V	2.3 V	16-WFQFN Exposed Pad
