SN74LVC373A Series

Octal Transparent D-Type Latch With 3-State Outputs

Catalog

Octal Transparent D-Type Latch With 3-State Outputs

Part	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Independent Circuits	Circuit	Package Name	Logic Type	Operating Temperature (Min)	Operating Temperature (Max)	Delay Time - Propagation	Output Type	Package Width	Package Length	Mounting Type	Current - Output Low	Current - Output High
Texas Instruments SN74LVC373ADGVR	3.6 V	1.65 V	1	8:8	20-TFSOP 20-TVSOP	D-Type Transparent Latch	-40 °C	85 °C	1.5 ns	Tri-State	4.4 mm	0.173 in	Surface Mount	24 mA	24 mA

Catalog

Octal Transparent D-Type Latch With 3-State Outputs

Description

The SN54LVC373A octal transparent D-type latch is designed for 2.7-V to 3.6-V VCCoperation, and the SN74LVC373A octal transparent D-type latch is designed for 1.65-V to 3.6-V VCCoperation. The SN54LVC373A octal transparent D-type latch is designed for 2.7-V to 3.6-V VCCoperation, and the SN74LVC373A octal transparent D-type latch is designed for 1.65-V to 3.6-V VCCoperation.
