DS80PCI810 Series
Manufacturer: Texas Instruments
Beta
⌘K
2.5/5.0/8.0-GBPS 8-CHANNEL LINEAR REDRIVER WITH EQUALIZATION
| Part | Current - Supply | Applications | Data Rate (Max) | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Capacitance - Input | Input | Output | Type | Operating Temperature (Min) | Operating Temperature (Max) | Package Name | Package Length | Package Width | Delay Time | Package / Case | Mounting Type | Number of Channels | Supplied Contents | Utilized IC / Part | Function | Embedded | Contents | Secondary Attributes | Primary Attributes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 220 mA | PCI Express® | 8 Gbps | 2.5 V | 3.3 V | 5 pF | CML | CML | Buffer ReDriver | -40 °C | 85 °C | 54-WQFN | 10 mm | 5.5 mm | 80 ps | 54-WFQFN Exposed Pad | Surface Mount | 8 | |||||||
 Texas Instruments | Interface | Board(s) | DS80PCI810 | Re-Driver | No | Board | On-Board LEDs | 8-Channel (Octal) | |||||||||||||||||
 Texas Instruments | 220 mA | PCI Express® | 8 Gbps | 2.5 V | 3.3 V | 5 pF | CML | CML | Buffer ReDriver | -40 °C | 85 °C | 54-WQFN | 10 mm | 5.5 mm | 80 ps | 54-WFQFN Exposed Pad | Surface Mount | 8 |
