LM7341 Series
Manufacturer: Texas Instruments
Beta
⌘K
SINGLE, 32-V, 4.6-MHZ OPERATIONAL AMPLIFIER
| Part | Voltage - Input Offset | Voltage - Supply Span (Max) | Number of Circuits | Mounting Type | Voltage - Supply Span (Min) | Current - Input Bias | Gain Bandwidth Product | Slew Rate | Current - Supply | Operating Temperature (Max) | Operating Temperature (Min) | Output Type | Package Name | Current - Output / Channel | Amplifier Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 200 µV | 32 V | 1 | Surface Mount | 2.5 V | 110 nA | 4.6 MHz | 1.9 V/µs | 700 µA | 125 °C | -40 °C | Rail-to-Rail | SOT-23-5 | 13 mA | General Purpose |
Texas Instruments | 200 µV | 32 V | 1 | Surface Mount | 2.5 V | 110 nA | 4.6 MHz | 1.9 V/µs | 700 µA | 125 °C | -40 °C | Rail-to-Rail | SOT-23-5 | 13 mA | General Purpose |
