LMH6586 Series
Manufacturer: Texas Instruments
Beta
⌘K
5-V, 32-INPUT 16-OUTPUT VIDEO CROSSPOINT SWITCH
| Part | Operating Temperature (Max) | Operating Temperature (Min) | Applications | Demultiplexer Outputs | Multiplexer Inputs | Mounting Type | -3db Bandwidth | Package / Case | Number of Channels | Voltage - Supply, Single (V+) (Minimum) | Voltage - Supply, Single (V+) (Maximum) | Features | Package Name | Supplied Contents | Type | Contents | Embedded | Utilized IC / Part | Function | Primary Attributes | Count |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 85 °C | -40 °C | Video | 16 | 32 | Surface Mount | 66 MHz | 80-TQFP | 1 | 4.5 V | 5.5 V | Buffered | 80-TQFP | ||||||||
 Texas Instruments | Board(s) Cable(s) | Interface | Board Cable | No | LMH6586 | Crosspoint Switch Multiplexer | 16 Video Crosspoint Switch 32 x 16 Video Crosspoint Switch | 32 | |||||||||||||
Texas Instruments | 85 °C | -40 °C | Video | 16 | 32 | Surface Mount | 66 MHz | 80-TQFP | 1 | 4.5 V | 5.5 V | Buffered | 80-TQFP |
