MSP430FR5969-SP Series
Manufacturer: Texas Instruments
Beta
⌘K
RADIATION HARDENED MIXED-SIGNAL MICROCONTROLLER
| Part | A/D Resolution (bits) | A/D Channels | Core Processor | Speed | Package Length | Package Name | Package Width | RAM Size Depth | RAM Size Width | Connectivity | Oscillator Type | Program Memory Type | Peripherals | Mounting Type | Package / Case | Number of I/O | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Supply (Vcc/Vdd) Maximum | Voltage - Supply (Vcc/Vdd) Minimum | Core Size (Bit Width) | Program Memory Depth | Program Memory Width | Program Memory Size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | ||||||||||||||||||||||||
 Texas Instruments | 12 bit | 16 count | CPUXV2 | 16 MHz | 7 mm | 48-HTQFP | 7 mm | 2 K | 8 bit | I2C IrDA LINbus SCI SPI UART USART | Internal | FRAM | Brown-out Detect DMA POR PWM Reset WDT | Surface Mount | 48-PowerTQFP | 40 | 105 °C | -55 °C | 3.6 V | 1.8 V | 16 Bit | 64 K | 8 bit | 64 KB |
