LM20146 Series
Manufacturer: Texas Instruments
Beta
⌘K
6A, ADJUSTABLE FREQUENCY SYNCHRONOUS BUCK REGULATOR
| Part | Operating Temperature (Max) | Operating Temperature (Min) | Mounting Type | Synchronous Rectifier | Voltage - Output (Min/Fixed) | Output Type | Frequency - Switching (Max) | Frequency - Switching (Min) | Current - Output | Voltage - Input (Min) | Voltage - Input (Max) | Package Length | Package Name | Package Width | Topology | Function | Number of Outputs | Voltage - Output (Max) | Output Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 125 °C | -40 °C | Surface Mount | Yes | 0.8 V | Adjustable | 750 kHz | 260 kHz | 6 A | 2.95 V | 5.5 V | 0.173 in | 16-HTSSOP 16-PowerTSSOP | 4.4 mm | Buck | Step-Down | 1 | 4.68 V | Positive |
Texas Instruments | 125 °C | -40 °C | Surface Mount | Yes | 0.8 V | Adjustable | 750 kHz | 260 kHz | 6 A | 2.95 V | 5.5 V | 0.173 in | 16-HTSSOP 16-PowerTSSOP | 4.4 mm | Buck | Step-Down | 1 | 4.68 V | Positive |
 Texas Instruments | 125 °C | -40 °C | Surface Mount | Yes | 0.8 V | Adjustable | 750 kHz | 260 kHz | 6 A | 2.95 V | 5.5 V | 0.173 in | 16-HTSSOP 16-PowerTSSOP | 4.4 mm | Buck | Step-Down | 1 | 4.68 V | Positive |
