LM49153 Series

Catalog

1.35-W, STEREO, ANALOG INPUT CLASS-AB AUDIO AMPLIFIER WITH NO-CLIP NOISE GATE

Part	Mounting Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Output Type	Maximum Output Power (per Channel)	Channels	Load Impedance	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)	Type	Package Name	Features	Board Type	Supplied Contents	Amplifier Type	Utilized IC / Part	Contents	Package Width	Package Length
Texas Instruments LM49153TME/NOPB	Surface Mount	5.5 V	2.7 V	1-Channel (Mono) 1-Channel (Mono) with Mono and Stereo Headphones Mono Stereo Headphones	1.35 W 25 mW	1 2	8 Ohm 32 Ohm	25-WFBGA DSBGA	85 °C	-40 °C	Class D Class G	25-DSBGA	Depop Differential Inputs I2C Input Multiplexer Shutdown Volume Control
Texas Instruments LM49153TMX/NOPB	Surface Mount	5.5 V	2.7 V	1-Channel (Mono) 1-Channel (Mono) with Mono and Stereo Headphones Mono Stereo Headphones	1.35 W 25 mW	1 2	8 Ohm 32 Ohm	25-WFBGA DSBGA	85 °C	-40 °C	Class D Class G	25-DSBGA	Depop Differential Inputs I2C Input Multiplexer Shutdown Volume Control
Texas Instruments LM49153TMEVAL		5.5 V	2.7 V	1-Channel (Mono) 1-Channel (Mono) with Mono and Stereo Headphones Mono Stereo Headphones	1.35 W 25 mW	1 2	8 Ohm 32 Ohm							Fully Populated	Board(s)	Class D Class G	LM49153	Board
Texas Instruments LM49153TMX/NOPB	Surface Mount	5.5 V	2.7 V	1-Channel (Mono) 1-Channel (Mono) with Mono and Stereo Headphones Mono Stereo Headphones	1.35 W 25 mW	1 2	8 Ohm 32 Ohm	25-WFBGA	85 °C	-40 °C	Class D Class G	25-BGA	Depop Differential Inputs I2C Input Multiplexer Shutdown Volume Control						2.01 mm	2.01 mm
