ADC12L066 Series
Manufacturer: Texas Instruments
Beta
⌘K
12-BIT, 66-MSPS, 450-MHZ INPUT BANDWIDTH ANALOG-TO-DIGITAL CONVERTER (ADC)
| Part | Number of Inputs | Voltage - Supply, Analog (Max) | Voltage - Supply, Analog (Min) | Reference Type | Architecture | Input Type | Configuration | Sampling Rate (Per Second) | Package / Case | Mounting Type | Number of A/D Converters | Number of Bits | Voltage - Supply, Digital (Max) | Voltage - Supply, Digital (Min) | Package Width | Package Name | Package Length | Operating Temperature (Min) | Operating Temperature (Max) | Ratio - ADC | Ratio - S/H | Data Interface |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 1 | 3.6 V | 3 V | External Internal | Pipelined | Differential | S/H-ADC | 66 MHz | 32-LQFP | Surface Mount | 1 count | 12 bits | 3.6 V | 1.8 V | 7 mm | 32-TQFP | 7 mm | -40 °C | 85 °C | 1 | 1 | Parallel |
Texas Instruments | 1 | 3.6 V | 3 V | External Internal | Pipelined | Differential | S/H-ADC | 66 MHz | 32-LQFP | Surface Mount | 1 count | 12 bits | 3.6 V | 1.8 V | 7 mm | 32-TQFP | 7 mm | -40 °C | 85 °C | 1 | 1 | Parallel |
