LP3952 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC LED DRV RGLTR PWM 36DSBGA
| Part | Voltage - Output | Voltage - Supply (Min) | Operating Temperature (Max) | Operating Temperature (Min) | Package / Case | Mounting Type | Number of Outputs | Voltage - Supply (Max) | Dimming | Applications | Frequency | Current - Output / Channel | Package Name | Package Length | Package Width | Type | Internal Switch(s) | Topology |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 5.3 V | 3 V | 85 °C | -30 °C | 36-WFBGA DSBGA | Surface Mount | 6 | 5.5 V | PWM | Backlight | 2 MHz | 40 mA | 36-DSBGA | 3.5 mm | 3.24 mm | DC DC Regulator | Yes | Step-Up (Boost) |
Texas Instruments | 5.3 V | 3 V | 85 °C | -30 °C | 36-WFBGA DSBGA | Surface Mount | 6 | 5.5 V | PWM | Backlight | 2 MHz | 40 mA | 36-DSBGA | DC DC Regulator | Yes | Step-Up (Boost) | ||
Texas Instruments | 5.3 V | 3 V | 85 °C | -30 °C | 36-WFBGA DSBGA | Surface Mount | 6 | 5.5 V | PWM | Backlight | 2 MHz | 40 mA | 36-DSBGA | 3.5 mm | 3.24 mm | DC DC Regulator | Yes | Step-Up (Boost) |
Texas Instruments | 5.3 V | 3 V | 85 °C | -30 °C | 36-WFBGA DSBGA | Surface Mount | 6 | 5.5 V | PWM | Backlight | 2 MHz | 40 mA | 36-DSBGA | DC DC Regulator | Yes | Step-Up (Boost) |
