BQ24296 Series
Manufacturer: Texas Instruments
Beta
⌘K
EVAL BOARD BATT CHARGER BQ24296
| Part | Supplied Contents | Utilized IC / Part | Contents | Secondary Attributes | Function | Type | Voltage - Supply (Max) | Mounting Type | Number of Cells | Package / Case | Package Length | Package Name | Package Width | Interface | Battery Pack Voltage | Charge Current - Max | Current - Charging | Operating Temperature (Max) | Operating Temperature (Min) | Battery Chemistry | Fault Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Board(s) | BQ24296 | Board | Graphical User Interface (GUI) I2C Interface(s) | Battery Charger | Power Management | |||||||||||||||
 Texas Instruments | 6.2 V | Surface Mount | 1 | 24-VFQFN Exposed Pad | 4 mm | 24-VQFN | 4 mm | I2C | 4.2 V | 3 A | Constant Programmable | 85 °C | -40 °C | Lithium Ion Polymer | Over Current Over Temperature Over Voltage | ||||||
 Texas Instruments | 6.2 V | Surface Mount | 1 | 24-VFQFN Exposed Pad | 4 mm | 24-VQFN | 4 mm | I2C | 4.2 V | 3 A | Constant Programmable | 85 °C | -40 °C | Lithium Ion Polymer | Over Current Over Temperature Over Voltage | ||||||
Texas Instruments | 6.2 V | Surface Mount | 1 | 24-VFQFN Exposed Pad | 4 mm | 24-VQFN | 4 mm | I2C | 4.2 V | 3 A | Constant Programmable | 85 °C | -40 °C | Lithium Ion Polymer | Over Current Over Temperature Over Voltage | ||||||
Texas Instruments | 6.2 V | Surface Mount | 1 | 24-VFQFN Exposed Pad | 4 mm | 24-VQFN | 4 mm | I2C | 4.2 V | 3 A | Constant Programmable | 85 °C | -40 °C | Lithium Ion Polymer | Over Current Over Temperature Over Voltage | ||||||
 Texas Instruments | Board(s) | BQ24296M | Board | Battery Charger | Power Management |
