LMD18200QML Series

2.4A, 55V H-Bridge

Catalog

2.4A, 55V H-Bridge

Part	Interface	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Current - Output	Mounting Type	Package Name	Technology	Package Feature	Package Features	Package Length	Package Width	Output Configuration	Low-Side Count	Motor Type - AC, DC	Operating Temperature (Min)	Operating Temperature (Max)	Function	Applications	Motor Type - Stepper	Voltage - Load (Min)	Voltage - Load (Max)
Texas Instruments LMD18200-2D/883	Parallel	12 VDC	55 V	3 A	Through Hole	24-CDIP 24-CDIP SB	Bi-CMOS DMOS	Window	Window	0.6 in	15.24 mm	Low Side	2	Brushed DC	-55 °C	125 °C	Control and Power Stage Driver - Fully Integrated	General Purpose	Bipolar	12 V	55 V

Catalog

2.4A, 55V H-Bridge

Description

The LMD18200 is a 2.4A H-Bridge designed for motion control applications. The device is built using a multi-technology process which combines bipolar and CMOS control circuitry with DMOS power devices on the same monolithic structure. Ideal for driving DC and stepper motors; the LMD18200 accommodates peak output currents up to 6A. An innovative circuit which facilitates low-loss sensing of the output current has been implemented. The LMD18200 is a 2.4A H-Bridge designed for motion control applications. The device is built using a multi-technology process which combines bipolar and CMOS control circuitry with DMOS power devices on the same monolithic structure. Ideal for driving DC and stepper motors; the LMD18200 accommodates peak output currents up to 6A. An innovative circuit which facilitates low-loss sensing of the output current has been implemented.
