74AXC4T774 Series
Manufacturer: Texas Instruments
Beta
⌘K
4-BIT DUAL-SUPPLY BUS TRANSCEIVER WITH 3-STATE OUTPUTS AND INDEPENDENT DIRECTION CONTROL INPUTS
| Part | Voltage - VCCB (Max) | Voltage - VCCB (Min) | Data Rate | Channels per Circuit | Output Type | Translator Type | Voltage - VCCA (Min) | Voltage - VCCA (Max) | Channel Type | Mounting Type | Package Name | Operating Temperature (Max) | Operating Temperature (Min) | Number of Circuits | Package Length | Package Width | Package / Case | Supplied Contents | Primary Attributes | Contents | Type | Utilized IC / Part | Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 3.6 V | 0.65 V | 310 Mbps | 4 | Non-Inverted Tri-State | Voltage Level | 0.65 V | 3.6 V | Bidirectional | Surface Mount | 16-TSSOP | 125 °C | -40 °C | 1 | 0.173 in | 4.4 mm | |||||||
 Texas Instruments | 3.6 V | 0.65 V | 310 Mbps | 4 | Non-Inverted Tri-State | Voltage Level | 0.65 V | 3.6 V | Bidirectional | Surface Mount | 16-UQFN | 125 °C | -40 °C | 1 | 2.6 mm | 1.8 mm | 16-UFQFN | ||||||
 Texas Instruments | Board(s) | 8-Channel (Octal) | Board | Interface | SN74AXC4T774 | Logic-Level Translator | |||||||||||||||||
 Texas Instruments | Surface Mount | 16-WQFN | 125 °C | -40 °C | 2.5 mm | 3.5 mm | 16-WFQFN Exposed Pad |
