DRV8804 Series

Catalog

MOTOR / MOTION / IGNITION CONTROLLERS & DRIVERS 1.5A UNIPOLAR STEPPR MOTOR DRIVER A 595-DRV8804PWP

Part	Voltage - Load (Max)	Voltage - Load (Min)	Mounting Type	Motor Type - Stepper	Low-Side Count	Output Configuration	Technology	Motor Type - AC, DC	Applications	Interface	Package Name	Package Length	Package Width	Current - Output	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Function	Operating Temperature (Min)	Operating Temperature (Max)	Supplied Contents	Contents	Primary Attributes	Utilized IC / Part	Embedded Bit Width	Embedded	Type
Texas Instruments DRV8804PWPR	60 V	8.2 V	Surface Mount	Unipolar	4	Low Side	Power MOSFET	Brushed DC	General Purpose	SPI	16-HTSSOP 16-PowerTSSOP	0.173 in	4.4 mm	1 A	60 V	8.2 V	Control and Power Stage Driver - Fully Integrated	-40 °C	150 °C
Texas Instruments DRV8804DWR	60 V	8.2 V	Surface Mount	Unipolar	4	Low Side	Power MOSFET	Brushed DC	General Purpose	SPI	20-SOIC	0.295 in	7.5 mm	800 mA	60 V	8.2 V	Control and Power Stage Driver - Fully Integrated	-40 °C	150 °C
Texas Instruments DRV8804DW	60 V	8.2 V	Surface Mount	Unipolar	4	Low Side	Power MOSFET	Brushed DC	General Purpose	SPI	20-SOIC	0.295 in	7.5 mm	800 mA	60 V	8.2 V	Control and Power Stage Driver - Fully Integrated	-40 °C	150 °C
Texas Instruments DRV8804EVM																	Motor Controller/Driver Stepper			Board(s)	Board	4 Channel Low-Side Driver	DRV8804	16 bit	MCU Yes	Power Management
Texas Instruments DRV8804PWP	60 V	8.2 V	Surface Mount	Unipolar	4	Low Side	Power MOSFET	Brushed DC	General Purpose	SPI	16-HTSSOP 16-PowerTSSOP	0.173 in	4.4 mm	1 A	60 V	8.2 V	Control and Power Stage Driver - Fully Integrated	-40 °C	150 °C
