HVDA551-Q1 Series

Automotive 5-V CAN Transceiver with I/O Level Adapting and Low-Power Mode Supply Optimization

Catalog

Automotive 5-V CAN Transceiver with I/O Level Adapting and Low-Power Mode Supply Optimization

Part	Package Name	Mounting Type	Protocol	Duplex	Receiver Hysteresis	Package Length	Package Width	Grade	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Number of Receivers	Number of Drivers	Qualification	Type
Texas Instruments HVDA551QDRQ1	8-SOIC	Surface Mount	CANbus	Half	200 mV	0.154 in	3.9 mm	Automotive	125 °C	-40 °C	5.33 V	4.68 V	2	1	AEC-Q100	Transceiver

Catalog

Automotive 5-V CAN Transceiver with I/O Level Adapting and Low-Power Mode Supply Optimization

Description

The HVDA55x-Q1 device is designed and qualified for use in automotive applications and meets or exceeds the specifications of the ISO 11898 High Speed CAN (Controller Area Network) Physical Layer standard (transceiver). The HVDA55x-Q1 device is designed and qualified for use in automotive applications and meets or exceeds the specifications of the ISO 11898 High Speed CAN (Controller Area Network) Physical Layer standard (transceiver).
