LM48520 Series

Catalog

IC AMP CLASS D STER 1.3W 25DSBGA

Part	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Mounting Type	Package Name	Package / Case	Type	Operating Temperature (Max)	Operating Temperature (Min)	Features	Channels	Load Impedance	Maximum Output Power (per Channel)	Output Type	Board Type	Supplied Contents	Utilized IC / Part	Contents	Amplifier Type	Package Length	Package Width
Texas Instruments LM48520TLX/NOPB	2.4 V	5.5 V	Surface Mount	25-DSBGA	25-WFBGA DSBGA	Class D	85 °C	-40 °C	Depop Differential Inputs Short-Circuit Protection Shutdown	2	8 Ohm	1.3 W	2-Channel (Stereo)
Texas Instruments LM48520TLBD	2.4 V	5.5 V								2	8 Ohm	1.3 W	2-Channel (Stereo)	Fully Populated	Board(s)	LM48520	Board	Class D
Texas Instruments LM48520TL/NOPB	2.4 V	5.5 V	Surface Mount	25-DSBGA	25-WFBGA DSBGA	Class D	85 °C	-40 °C	Depop Differential Inputs Short-Circuit Protection Shutdown	2	8 Ohm	1.3 W	2-Channel (Stereo)						2.46 mm	2.46 mm
Texas Instruments LM48520TLE/NOPB	2.4 V	5.5 V	Surface Mount	25-DSBGA	25-WFBGA DSBGA	Class D	85 °C	-40 °C	Depop Differential Inputs Short-Circuit Protection Shutdown	2	8 Ohm	1.3 W	2-Channel (Stereo)
Texas Instruments LM48520TL/NOPB	2.4 V	5.5 V	Surface Mount	25-DSBGA	25-WFBGA DSBGA	Class D	85 °C	-40 °C	Depop Differential Inputs Short-Circuit Protection Shutdown	2	8 Ohm	1.3 W	2-Channel (Stereo)
