LMK04033 Series

Catalog

BOARD EVALUATION LMK04033

Part	Supplied Contents	Embedded	Contents	Type	Function	Primary Attributes	Secondary Attributes	Utilized IC / Part	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Mounting Type	Input	Package Width	Package Name	Package Length	Output	Frequency - Max	Number of Circuits	PLL	Input Ratio	Output Ratio	Package / Case	Divider	Multiplier	Differential Input	Differential Output
Texas Instruments LMK04033BEVAL/NOPB	Board(s) Cable(s)	No	Board Cable	Timing	Clock Conditioner	2VPECL LVCMOS Outputs LVDS LVPECL	Integrated PLL and VCO	LMK04033
Texas Instruments LMK04033BISQE/NOPB				Clock Conditioner					-40 °C	85 °C	3.15 V	3.45 V	Surface Mount	LVCMOS LVDS LVPECL	7 mm	48-WQFN	7 mm	2VPECL LVCMOS LVDS LVPECL	2.16 GHz	1	Yes	2	6	48-WFQFN Exposed Pad	Yes	Yes	Yes	Yes
Texas Instruments LMK04033BEVAL	Board(s) Cable(s)	No	Board Cable	Timing	Clock Conditioner	122.88MHz VCXO	Integrated PLL and VCO	LMK04033
Texas Instruments LMK04033BISQE/NOPB				Clock Conditioner					-40 °C	85 °C	3.15 V	3.45 V	Surface Mount	LVCMOS LVDS LVPECL	7 mm	48-WQFN	7 mm	2VPECL LVCMOS LVDS LVPECL	2.16 GHz	1	Yes	2	6	48-WFQFN Exposed Pad	Yes	Yes	Yes	Yes
Texas Instruments LMK04033BISQX/NOPB				Clock Conditioner					-40 °C	85 °C	3.15 V	3.45 V	Surface Mount	LVCMOS LVDS LVPECL	7 mm	48-WQFN	7 mm	2VPECL LVCMOS LVDS LVPECL	2.16 GHz	1	Yes	2	6	48-WFQFN Exposed Pad	Yes	Yes	Yes	Yes
Texas Instruments LMK04033BISQ/NOPB				Clock Conditioner					-40 °C	85 °C	3.15 V	3.45 V	Surface Mount	LVCMOS LVDS LVPECL	7 mm	48-WQFN	7 mm	2VPECL LVCMOS LVDS LVPECL	2.16 GHz	1	Yes	2	6	48-WFQFN Exposed Pad	Yes	Yes	Yes	Yes
