LM2794 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC LED DRV RGLTR PWM 20MA 14USMD
| Part | Dimming | Voltage - Supply (Min) | Voltage - Output | Package Name | Applications | Current - Output / Channel | Number of Outputs | Operating Temperature (Max) | Operating Temperature (Min) | Topology | Package / Case | Frequency | Mounting Type | Internal Switch(s) | Type | Voltage - Supply (Max) | Package Length | Package Width |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Analog PWM | 2.7 V | 3.8 V | 14-DSBGA | Backlight | 20 mA | 4 | 85 °C | -30 °C | Switched Capacitor (Charge Pump) | 14-WFBGA DSBGA | 515 kHz | Surface Mount | Yes | DC DC Regulator | 5.5 V | ||
 Texas Instruments | Analog PWM | 2.7 V | 3.8 V | 14-DSBGA | Backlight | 20 mA | 4 | 85 °C | -30 °C | Switched Capacitor (Charge Pump) | 14-WFBGA DSBGA | 515 kHz | Surface Mount | Yes | DC DC Regulator | 5.5 V | ||
 Texas Instruments | Analog PWM | 2.7 V | 3.8 V | 14-DSBGA | Backlight | 20 mA | 4 | 85 °C | -30 °C | Switched Capacitor (Charge Pump) | 14-WFBGA DSBGA | 515 kHz | Surface Mount | Yes | DC DC Regulator | 5.5 V | ||
Texas Instruments | Analog PWM | 2.7 V | 3.8 V | 14-DSBGA | Backlight | 20 mA | 4 | 85 °C | -30 °C | Switched Capacitor (Charge Pump) | 14-WFBGA DSBGA | 515 kHz | Surface Mount | Yes | DC DC Regulator | 5.5 V | ||
 Texas Instruments | Analog PWM | 2.7 V | 3.8 V | 14-DSBGA | Backlight | 20 mA | 4 | 85 °C | -30 °C | Switched Capacitor (Charge Pump) | 14-WFBGA DSBGA | 515 kHz | Surface Mount | Yes | DC DC Regulator | 5.5 V | ||
Texas Instruments | Analog PWM | 2.7 V | 3.8 V | 14-µSMD | Backlight | 20 mA | 4 | 85 °C | -30 °C | Switched Capacitor (Charge Pump) | 14-WFBGA | 515 kHz | Surface Mount | Yes | DC DC Regulator | 5.5 V | 2.1 mm | 2.4 mm |
