DRV10866 Series
Manufacturer: Texas Instruments
Beta
⌘K
5-V NOMINAL, 0.85-A PEAK SENSORLESS TRAPEZOIDAL CONTROL, 3-PHASE BLDC MOTOR DRIVER
| Part | Interface | Half-Bridge Count | Output Configuration | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Package Length | Package Name | Package Width | Voltage - Load (Max) | Voltage - Load (Min) | Current - Output | Function | Motor Type - AC, DC | Mounting Type | Technology | Package / Case | Operating Temperature (Max) | Operating Temperature (Min) | Applications | Supplied Contents | Secondary Attributes | Contents | Primary Attributes | Type | Utilized IC / Part | Embedded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | PWM | 3 | Half-Bridge | 1.65 V | 5.5 V | 3 mm | 10-WSON | 3 mm | 5.5 V | 1.65 V | 800 mA | Control and Power Stage Driver - Fully Integrated | Brushless DC (BLDC) | Surface Mount | Power MOSFET | 10-WFDFN Exposed Pad | 125 °C | -40 °C | Fan Motor Driver | |||||||
 Texas Instruments | Driver Motor Controller | Board(s) | Potentiometer Speed Control | Board | Motors (BLDC) | Power Management | DRV10866 | No |
