DRV8813 Series

Catalog

45-V, 2.5-A BIPOLAR STEPPER OR DUAL H-BRIDGE MOTOR DRIVER WITH CURRENT REGULATION

Part	Applications	Voltage - Load (Min)	Voltage - Load (Max)	Operating Temperature (Min)	Operating Temperature (Max)	Package Width	Package Name	Package Length	Interface	Function	Motor Type - Stepper	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Half-Bridge Count	Output Configuration	Mounting Type	Technology	Current - Output	Motor Type - AC, DC	Supplied Contents	Embedded Bit Width	Embedded	Utilized IC / Part	Primary Attributes	Contents	Type	Secondary Attributes
Texas Instruments DRV8813PWP	General Purpose	8.2 V	45 V	-40 °C	150 °C	4.4 mm	28-HTSSOP 28-PowerTSSOP	0.173 in	Parallel	Control and Power Stage Driver - Fully Integrated	Bipolar	45 V	8.2 V	4	Half Bridge	Surface Mount	Power MOSFET	2.5 A	Brushed DC
Texas Instruments DRV8813PWPR	General Purpose	8.2 V	45 V	-40 °C	150 °C	4.4 mm	28-HTSSOP 28-PowerTSSOP	0.173 in	Parallel	Control and Power Stage Driver - Fully Integrated	Bipolar	45 V	8.2 V	4	Half Bridge	Surface Mount	Power MOSFET	2.5 A	Brushed DC
Texas Instruments DRV8813EVM										Driver Motor Controller										Board(s)	16 bit	MCU Yes	DRV8813	2 Channel H-Bridge Driver	Board	Power Management	Short-Circuit Thermal and Undervoltage Protection
