LMP7300 Series

Catalog

MICROPOWER, PRECISION, SINGLE COMPARATOR WITH ADJUSTABLE HYSTERESIS FUNCTION

Part	Type	PSRR (Typ)	CMRR (Typ)	Current - Quiescent (Max)	Package Width	Package Name	Package Length	Current - Input Bias (Max)	Propagation Delay (Max)	Output Type	Number of Elements	Mounting Type	Hysteresis	Operating Temperature (Max)	Operating Temperature (Min)	Supply Configuration	Voltage - Supply (Dual) Maximum (Magnitude)	Voltage - Supply (Single) Minimum	Voltage - Supply (Dual) Minimum (Magnitude)	Voltage - Supply (Single) Maximum	Voltage - Input Offset (Max)
Texas Instruments LMP7300MMX/NOPB	with Voltage Reference	100 dB	100 dB	13 µA	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	0.003 µA	15 µs	CMOS Open-Collector TTL	1	Surface Mount	1 mV	125 °C	-40 °C	Dual Single	6 V	2.7 V	1.35 V	12 V	1 mV
Texas Instruments LMP7300MAX/NOPB	with Voltage Reference	100 dB	100 dB	13 µA	3.9 mm	8-SOIC	0.154 in	0.003 µA	15 µs	CMOS Open-Collector TTL	1	Surface Mount	1 mV	125 °C	-40 °C	Dual Single	6 V	2.7 V	1.35 V	12 V	0.75 mV
Texas Instruments LMP7300MA/NOPB	with Voltage Reference	100 dB	100 dB	13 µA	3.9 mm	8-SOIC	0.154 in	0.003 µA	15 µs	CMOS Open-Collector TTL	1	Surface Mount	1 mV	125 °C	-40 °C	Dual Single	6 V	2.7 V	1.35 V	12 V	0.75 mV
Texas Instruments LMP7300MM/NOPB	with Voltage Reference	100 dB	100 dB	13 µA	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	0.003 µA	15 µs	CMOS Open-Collector TTL	1	Surface Mount	1 mV	125 °C	-40 °C	Dual Single	6 V	2.7 V	1.35 V	12 V	1 mV
Texas Instruments LMP7300MME/NOPB	with Voltage Reference	100 dB	100 dB	13 µA	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	0.003 µA	15 µs	CMOS Open-Collector TTL	1	Surface Mount	1 mV	125 °C	-40 °C	Dual Single	6 V	2.7 V	1.35 V	12 V	1 mV
