74HCT365 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC BUF NON-INVERT 5.5V 16SOIC
| Part | Operating Temperature (Max) | Operating Temperature (Min) | Number of Elements | Current - Output Low | Current - Output High | Output Type | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Number of Bits per Element | Package Name | Logic Type | Package Width | Package Length | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 125 °C | -55 °C | 1 | 4 mA | 4 mA | 3-State | 5.5 V | 4.5 V | 6 bits | 16-SOIC | Buffer Non-Inverting | 3.9 mm | 0.154 in | Surface Mount |
 Texas Instruments | 125 °C | -55 °C | 1 | 4 mA | 4 mA | 3-State | 5.5 V | 4.5 V | 6 bits | 16-SOIC | Buffer Non-Inverting | 3.9 mm | 0.154 in | Surface Mount |
 Texas Instruments | 125 °C | -55 °C | 1 | 4 mA | 4 mA | 3-State | 5.5 V | 4.5 V | 6 bits | 16-DIP 16-PDIP | Buffer Non-Inverting | 7.62 mm | 0.3 in | Through Hole |
Texas Instruments | 125 °C | -55 °C | 1 | 4 mA | 4 mA | 3-State | 5.5 V | 4.5 V | 6 bits | 16-SOIC | Buffer Non-Inverting | 3.9 mm | 0.154 in | Surface Mount |
