SN75DP120 Series

Catalog

DISPLAY PORT DUAL-MODE REPEATER INTERFACE

Part	Output	Package Length	Package Name	Package Width	Number of Channels	Data Rate (Max)	Type	Delay Time	Current - Supply	Input	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)	Signal Conditioning	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Applications	Mounting Type
Texas Instruments SN75DP120RHHR	DisplayPort	6 mm	36-VQFN	6 mm	4	2.7 Gbps	Buffer ReDriver	6.4 ns	165 mA	DisplayPort	36-VFQFN Exposed Pad	85 °C	0 °C	Input Equalization Output Pre-Emphasis	3.6 V	3 V	DisplayPort	Surface Mount
Texas Instruments SN75DP120RHHT	DisplayPort	6 mm	36-VQFN	6 mm	4	2.7 Gbps	Buffer ReDriver	6.4 ns	165 mA	DisplayPort	36-VFQFN Exposed Pad	85 °C	0 °C	Input Equalization Output Pre-Emphasis	3.6 V	3 V	DisplayPort	Surface Mount
