LT1054 Series

Catalog

3.5 V TO 15 VIN, 100-MA OUTPUT CURRENT SWITCHED-CAPACITOR VOLTAGE CONVERTERS WITH REGULATOR

Part	Package Length	Package Name	Package Width	Synchronous Rectifier	Current - Output	Output Type	Function	Topology	Voltage - Input (Min)	Frequency - Switching	Voltage - Input (Max)	Voltage - Output (Max)	Number of Outputs	Mounting Type	Output Configuration	Voltage - Output (Min/Fixed)	Operating Temperature (Min)	Operating Temperature (Max)
Texas Instruments LT1054CDWR	0.295 in	16-SOIC	7.5 mm	No	100 mA	Adjustable (Fixed)	Ratiometric Step-Up	Charge Pump	3.5 V	25 kHz	15 V	26.4 V	1	Surface Mount	Negative Positive Positive or Negative	3.5 V	0 °C	70 °C
Texas Instruments LT1054IP	0.3 in	8-DIP 8-PDIP	7.62 mm	No	100 mA	Adjustable (Fixed)	Ratiometric Step-Up	Charge Pump	3.5 V	25 kHz	15 V	26.4 V	1	Through Hole	Negative Positive Positive or Negative	3.5 V	-40 °C	85 °C
Texas Instruments LT1054CPG4	0.3 in	8-DIP 8-PDIP	7.62 mm	No	100 mA	Adjustable (Fixed)	Ratiometric Step-Up	Charge Pump	3.5 V	25 kHz	15 V	26.4 V	1	Through Hole	Negative Positive Positive or Negative	3.5 V	0 °C	70 °C
Texas Instruments LT1054CP	0.3 in	8-DIP 8-PDIP	7.62 mm	No	100 mA	Adjustable (Fixed)	Ratiometric Step-Up	Charge Pump	3.5 V	25 kHz	15 V	26.4 V	1	Through Hole	Negative Positive Positive or Negative	3.5 V	0 °C	70 °C
Texas Instruments LT1054CPE4	0.3 in	8-DIP 8-PDIP	7.62 mm	No	100 mA	Adjustable (Fixed)	Step-Up	Charge Pump	3.5 V	25 kHz	15 V	-15 V	1	Through Hole	Negative Positive Positive or Negative	-1.25 V	0 °C	70 °C
Texas Instruments LT1054IPE4	0.3 in	8-DIP 8-PDIP	7.62 mm	No	100 mA	Adjustable (Fixed)	Step-Up	Charge Pump	3.5 V	25 kHz	15 V	-15 V	1	Through Hole	Negative Positive Positive or Negative	-1.25 V	-40 °C	85 °C
Texas Instruments LT1054IDWG4	0.295 in	16-SOIC	7.5 mm	No	100 mA	Adjustable (Fixed)	Ratiometric Step-Up	Charge Pump	3.5 V	25 kHz	15 V	26.4 V	1	Surface Mount	Negative Positive Positive or Negative	3.5 V	-40 °C	85 °C
Texas Instruments LT1054CDWRE4	0.295 in	16-SOIC	7.5 mm	No	100 mA	Adjustable (Fixed)	Ratiometric Step-Up	Charge Pump	3.5 V	25 kHz	15 V	26.4 V	1	Surface Mount	Negative Positive Positive or Negative	3.5 V	0 °C	70 °C
Texas Instruments LT1054CDWRG4	0.295 in	16-SOIC	7.5 mm	No	100 mA	Adjustable (Fixed)	Ratiometric Step-Up	Charge Pump	3.5 V	25 kHz	15 V	26.4 V	1	Surface Mount	Negative Positive Positive or Negative	3.5 V	0 °C	70 °C
Texas Instruments LT1054IPG4	0.3 in	8-DIP 8-PDIP	7.62 mm	No	100 mA	Adjustable (Fixed)	Ratiometric Step-Up	Charge Pump	3.5 V	25 kHz	15 V	26.4 V	1	Through Hole	Negative Positive Positive or Negative	3.5 V	-40 °C	85 °C
