ADC12C105 Series

Catalog

12-BIT, 105-MSPS, 1.0-GHZ INPUT BANDWIDTH ANALOG-TO-DIGITAL CONVERTER (ADC)

Part	Architecture	Number of Bits	Ratio - ADC	Ratio - S/H	Package Length	Package Name	Package Width	Sampling Rate (Per Second)	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Operating Temperature (Min)	Operating Temperature (Max)	Configuration	Mounting Type	Data Interface	Number of Inputs	Package / Case	Input Type	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Number of A/D Converters	Reference Type
Texas Instruments ADC12C105CISQ/NOPB	Pipelined	12 bits	1	1	5 mm	32-WQFN	5 mm	105 MHz	2.4 V	3.6 V	-40 °C	85 °C	S/H-ADC	Surface Mount	Parallel	1	32-WFQFN Exposed Pad	Differential	2.7 V	3.6 V	1 count	External Internal
Texas Instruments ADC12C105CISQE/NOPB	Pipelined	12 bits	1	1	5 mm	32-WQFN	5 mm	105 MHz	2.4 V	3.6 V	-40 °C	85 °C	S/H-ADC	Surface Mount	Parallel	1	32-WFQFN Exposed Pad	Differential	2.7 V	3.6 V	1 count	External Internal
