MMBZ30VCL Series

Two-channel common cathode ESD protection in SOT-23

Catalog

Two-channel common cathode ESD protection in SOT-23

Part	Package / Case	Package Name	Power Line Protection	Capacitance	Voltage - Clamping (Max)	Unidirectional Channels	Type	Power - Peak Pulse	Voltage - Reverse Standoff (Max)	Voltage - Breakdown (Min)	Mounting Type	Applications	Current - Peak Pulse	Operating Temperature (Min)	Operating Temperature (Max)
Texas Instruments MMBZ30VCLDBZR	SC-59 SOT-23-3 TO-236-3	SOT-23-3	No	4.5 pF	40 V	2	Zener	20 W	24 V	24.8 V	Surface Mount	Telecom	500 mA	-55 °C	150 °C

Catalog

Two-channel common cathode ESD protection in SOT-23

Description

The MMBZ30VCL is a dual channel unidirectional or single channel bidirectional ESD in a common cathode configuration. The device’s low capacitance and low leakage features enable use in high speed applications. The low dynamic resistance allows low clamping voltage to help protect systems against transient events. The MMBZ30VCL is packaged in the SOT-23, providing two channels of robust transient protection in one space-efficient form factor. The MMBZ30VCL is a dual channel unidirectional or single channel bidirectional ESD in a common cathode configuration. The device’s low capacitance and low leakage features enable use in high speed applications. The low dynamic resistance allows low clamping voltage to help protect systems against transient events. The MMBZ30VCL is packaged in the SOT-23, providing two channels of robust transient protection in one space-efficient form factor.
