INA114 Series

Catalog

1-MHZ, 50-ΜV, 11-NV/√HZ, 3MA-POWER, PRECISION INSTRUMENTATION AMPLIFIER

Part	-3db Bandwidth	Package Name	Slew Rate	Current - Output / Channel	Current - Supply	Package Length	Package Width	Voltage - Supply Span (Max)	Amplifier Type	Voltage - Input Offset	Number of Circuits	Voltage - Supply Span (Min)	Mounting Type	Current - Input Bias	Operating Temperature (Min)	Operating Temperature (Max)
Texas Instruments INA114BP	1 MHz	8-DIP 8-PDIP	0.6 V/µs	20 mA	2.2 mA	0.3 in	7.62 mm	36 V	Instrumentation	10 ĄV	1	4.5 V	Through Hole	500 pA	-40 °C	85 °C
Texas Instruments INA114BU	1 MHz	16-SOIC	0.6 V/µs	20 mA	2.2 mA	0.295 in	7.5 mm	36 V	Instrumentation	10 ĄV	1	4.5 V	Surface Mount	500 pA	-40 °C	85 °C
Texas Instruments INA114APG4	1 MHz	8-DIP 8-PDIP	0.6 V/µs	20 mA	2.2 mA	0.3 in	7.62 mm	36 V	Instrumentation	25 µV	1	4.5 V	Through Hole	500 pA	-40 °C	85 °C
Texas Instruments INA114AU/1K	1 MHz	16-SOIC	0.6 V/µs	20 mA	2.2 mA	0.295 in	7.5 mm	36 V	Instrumentation	25 µV	1	4.5 V	Surface Mount	500 pA	-40 °C	85 °C
Texas Instruments INA114BU/1K	1 MHz	16-SOIC	0.6 V/µs	20 mA	2.2 mA	0.295 in	7.5 mm	36 V	Instrumentation	10 ĄV	1	4.5 V	Surface Mount	500 pA	-40 °C	85 °C
Texas Instruments INA114AU	1 MHz	16-SOIC	0.6 V/µs	20 mA	2.2 mA	0.295 in	7.5 mm	36 V	Instrumentation	25 µV	1	4.5 V	Surface Mount	500 pA	-40 °C	85 °C
Texas Instruments INA114BPG4	1 MHz	8-DIP 8-PDIP	0.6 V/µs	20 mA	2.2 mA	0.3 in	7.62 mm	36 V	Instrumentation	10 ĄV	1	4.5 V	Through Hole	500 pA	-40 °C	85 °C
Texas Instruments INA114AU/1KG4	1 MHz	16-SOIC	0.6 V/µs	20 mA	2.2 mA	0.295 in	7.5 mm	36 V	Instrumentation	25 µV	1	4.5 V	Surface Mount	500 pA	-40 °C	85 °C
Texas Instruments INA114AP	1 MHz	8-DIP 8-PDIP	0.6 V/µs	20 mA	2.2 mA	0.3 in	7.62 mm	36 V	Instrumentation	25 µV	1	4.5 V	Through Hole	500 pA	-40 °C	85 °C
