TL7700 Series

Catalog

IC SUPERVISOR 1 CHANNEL 8TSSOP

Part	Package Length	Package Name	Package Width	Reset	Type	Mounting Type	Reset Timeout Description	Reset Timeout	Output	Operating Temperature (Max)	Operating Temperature (Min)	Number of Voltages Monitored	Voltage - Threshold
Texas Instruments TL7700CPWRG4	0.173 in	8-TSSOP	4.4 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CPW	0.173 in	8-TSSOP	4.4 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CDGKT	0.118 in	8-TSSOP 8-MSOP 8-VSSOP	3 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CPWRE4	0.173 in	8-TSSOP	4.4 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CPWG4	0.173 in	8-TSSOP	4.4 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CPS	0.209 in	8-SO 8-SOIC	5.3 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CPWR	0.173 in	8-TSSOP	4.4 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CPSR	0.209 in	8-SO 8-SOIC	5.3 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CP	0.3 in	8-DIP 8-PDIP	7.62 mm	Active Low	Simple Reset/Power-On Reset	Through Hole	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
Texas Instruments TL7700CDGKR	0.118 in	8-TSSOP 8-MSOP 8-VSSOP	3 mm	Active Low	Simple Reset/Power-On Reset	Surface Mount	Maximum Propagation Delay	10 µs	Open Collector Open Drain	85 °C	-40 °C	1	Adjustable Selectable
