ADC12DL080 Series

Catalog

DUAL-CHANNEL, 12-BIT, 80-MSPS, 600-MHZ INPUT BANDWIDTH ANALOG-TO-DIGITAL CONVERTER (ADC)

Part	Architecture	Package / Case	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Number of A/D Converters	Package Width	Package Name	Package Length	Input Type	Features	Mounting Type	Reference Type	Number of Inputs	Sampling Rate (Per Second)	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Ratio - ADC	Ratio - S/H	Data Interface	Operating Temperature (Min)	Operating Temperature (Max)	Configuration	Number of Bits
Texas Instruments ADC12DL080CIVS/NOPB	Pipelined	64-TQFP	2.4 V	3.6 V	2 count	10 mm	64-TQFP	10 mm	Differential	Simultaneous Sampling	Surface Mount	External Internal	2	80 MHz	3.6 V	3 V	1	1	Parallel	-40 °C	85 °C	S/H-ADC	12 bits
Texas Instruments ADC12DL080CIVS/NOPB	Pipelined	64-TQFP	2.4 V	3.6 V	2 count	10 mm	64-TQFP	10 mm	Differential	Simultaneous Sampling	Surface Mount	External Internal	2	80 MHz	3.6 V	3 V	1	1	Parallel	-40 °C	85 °C	S/H-ADC	12 bits
