LMC660 Series

Catalog

IC CMOS 4 CIRCUIT 14SOIC

Part	Voltage - Supply Span (Max)	Current - Output / Channel	Voltage - Input Offset	Slew Rate	Mounting Type	Voltage - Supply Span (Min)	Number of Circuits	Package Name	Output Type	Amplifier Type	Package Width	Package Length	Current - Input Bias	Operating Temperature (Min)	Operating Temperature (Max)	Gain Bandwidth Product	Current - Supply
Texas Instruments LMC660AIMX	15.5 V	40 mA	1 mV	1.1 V/µs	Surface Mount	4.75 V	4	14-SOIC	Push-Pull Rail-to-Rail	CMOS	3.9 mm	0.154 in	0.002 pA	-40 °C	85 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660CN/NOPB	15.5 V	40 mA	1 mV	1.1 V/µs	Through Hole	4.75 V	4	14-DIP 14-PDIP	Push-Pull Rail-to-Rail	CMOS	7.62 mm	0.3 in	0.002 pA	0 °C	70 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660AIM	15.5 V	40 mA	1 mV	1.1 V/µs	Surface Mount	4.75 V	4	14-SOIC	Push-Pull Rail-to-Rail	CMOS	3.9 mm	0.154 in	0.002 pA	-40 °C	85 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660AIMX	15.5 V	40 mA	1 mV	1.1 V/µs	Surface Mount	4.75 V	4	14-SOIC	Push-Pull Rail-to-Rail	CMOS	3.9 mm	0.154 in	0.002 pA	-40 °C	85 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660CMX/ELLD734	15.5 V	40 mA	1 mV	1.1 V/µs	Surface Mount	4.75 V	4	14-SOIC	Push-Pull Rail-to-Rail	CMOS	3.9 mm	0.154 in	0.002 pA	0 °C	70 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660CMX	15.5 V	40 mA	1 mV	1.1 V/µs	Surface Mount	4.75 V	4	14-SOIC	Push-Pull Rail-to-Rail	CMOS	3.9 mm	0.154 in	0.002 pA	0 °C	70 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660CM	15.5 V	40 mA	1 mV	1.1 V/µs	Surface Mount	4.75 V	4	14-SOIC	Push-Pull Rail-to-Rail	CMOS	3.9 mm	0.154 in	0.002 pA	0 °C	70 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660CN	15.5 V	40 mA	1 mV	1.1 V/µs	Through Hole	4.75 V	4	14-DIP 14-PDIP	Push-Pull Rail-to-Rail	CMOS	7.62 mm	0.3 in	0.002 pA	0 °C	70 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660AIM	15.5 V	40 mA	1 mV	1.1 V/µs	Surface Mount	4.75 V	4	14-SOIC	Push-Pull Rail-to-Rail	CMOS	3.9 mm	0.154 in	0.002 pA	-40 °C	85 °C	1.4 MHz	1.5 mA
Texas Instruments LMC660AIMX/NOPB	15.5 V	40 mA	1 mV	1.1 V/µs	Surface Mount	4.75 V	4	14-SOIC	Push-Pull Rail-to-Rail	CMOS	3.9 mm	0.154 in	0.002 pA	-40 °C	85 °C	1.4 MHz	1.5 mA
