DS80PCI402 Series

Catalog

INTERFACE - SIGNAL BUFFERS, REPEATERS 4 LANE PCI EXPRESS R EPEATER A 595-DS80PCI402SQENPB

Part	Package Name	Package Length	Package Width	Data Rate (Max)	Capacitance - Input	Type	Package / Case	Operating Temperature (Min)	Operating Temperature (Max)	Mounting Type	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Applications	Signal Conditioning	Delay Time	Input	Output	Number of Channels	Supplied Contents	Utilized IC / Part	Function	Contents
Texas Instruments DS80PCI402SQ/NOPB	54-WQFN	10 mm	5.5 mm	8 Gbps	10 pF	Buffer ReDriver	54-WFQFN Exposed Pad	-40 °C	85 °C	Surface Mount	2.375 V	3.6 V	PCIe	Input Equalization Output De-Emphasis	200 ps	CML	CML	8
Texas Instruments DS80PCI402SQE/NOPB	54-WQFN	10 mm	5.5 mm	8 Gbps	10 pF	Buffer ReDriver	54-WFQFN Exposed Pad	-40 °C	85 °C	Surface Mount	2.375 V	3.6 V	PCIe	Input Equalization Output De-Emphasis	200 ps	CML	CML	8
Texas Instruments DS80PCI402EVK/NOPB						Interface													Board(s)	DS80PCI402	PCI Express Transceiver	Board
