OPA4191 Series

Catalog

QUAD, LOW-POWER, 36-V, PRECISION, E-TRIM AMPLIFIER WITH RRIO

Part	Amplifier Type	Number of Circuits	Mounting Type	Voltage - Input Offset	Gain Bandwidth Product	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply Span (Min)	Slew Rate	Package / Case	Current - Output / Channel	Output Type	Current - Supply	Voltage - Supply Span (Max)	Current - Input Bias	Package Width	Package Name	Package Length
Texas Instruments OPA4191IRUMT	CMOS	4	Surface Mount	5 µV	2.5 MHz	125 °C	-40 °C	4.5 V	7.5 V/µs	16-WQFN Exposed Pad	65 mA	Rail-to-Rail	140 µA	36 V	5 pA	4 mm	16-WQFN	4 mm
Texas Instruments OPA4191IRUMR	CMOS	4	Surface Mount	5 µV	2.5 MHz	125 °C	-40 °C	4.5 V	7.5 V/µs	16-WQFN Exposed Pad	65 mA	Rail-to-Rail	140 µA	36 V	5 pA	4 mm	16-WQFN	4 mm
Texas Instruments OPA4191ID	CMOS	4	Surface Mount	5 µV	2.5 MHz	125 °C	-40 °C	4.5 V	5 V/µs		65 mA	Rail-to-Rail	140 µA	36 V	5 pA	3.9 mm	14-SOIC	0.154 in
Texas Instruments OPA4191IPWR	CMOS	4	Surface Mount	5 µV	2.5 MHz	125 °C	-40 °C	4.5 V	7.5 V/µs		65 mA	Rail-to-Rail	140 µA	36 V	5 pA	4.4 mm	14-TSSOP	0.173 in
Texas Instruments OPA4191IPWT	CMOS	4	Surface Mount	5 µV	2.5 MHz	125 °C	-40 °C	4.5 V	7.5 V/µs		65 mA	Rail-to-Rail	140 µA	36 V	5 pA	4.4 mm	14-TSSOP	0.173 in
