LMX2470 Series

Catalog

2.6-GHZ DELTA-SIGMA FRACTIONAL-N PLL WITH 800-MHZ INTEGER-N PLL

Part	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Frequency - Max	Differential Input	Differential Output	PLL	Mounting Type	Package Name	Package Length	Package Width	Input	Divider	Multiplier	Number of Circuits	Type	Output	Package / Case	Input Ratio	Output Ratio	Supplied Contents	Embedded	Utilized IC / Part	Primary Attributes	Contents	Function
Texas Instruments LMX2470SLEX	-40 °C	85 °C	2.25 V	2.75 V	2.6 GHz	Yes	No	Yes with Bypass	Surface Mount	24-ULGA	4.5 mm	3.5 mm	CMOS	Yes	Yes	1	Delta Sigma PLL Frequency Synthesizer	CMOS	24-UFQFN	3	3
Texas Instruments LMX2470SLEX/NOPB	-40 °C	85 °C	2.25 V	2.75 V	2.6 GHz	Yes	No	Yes with Bypass	Surface Mount	24-ULGA	4.5 mm	3.5 mm	CMOS	Yes	Yes	1	Delta Sigma PLL Frequency Synthesizer	CMOS	24-UFQFN	3	3
Texas Instruments LMX2470SLEX	-40 °C	85 °C	2.25 V	2.75 V	2.6 GHz	Yes	No	Yes with Bypass	Surface Mount	24-ULGA	4.5 mm	3.5 mm	CMOS	Yes	Yes	1	Delta Sigma PLL Frequency Synthesizer	CMOS	24-UFQFN	3	3
Texas Instruments LMX2470SLEX/NOPB	-40 °C	85 °C	2.25 V	2.75 V	2.6 GHz	Yes	No	Yes with Bypass	Surface Mount	24-ULGA	4.5 mm	3.5 mm	CMOS	Yes	Yes	1	Delta Sigma PLL Frequency Synthesizer	CMOS	24-UFQFN	3	3
Texas Instruments LMX2470EVAL																	Timing					Board(s)	No	LMX2470	Integer-N PLL Single Fractional-N Single Fractional-N and Integer-N PLL	Board	Frequency Synthesizer
