LM3485 Series
Manufacturer: Texas Instruments
Beta
⌘K
4.5-35V, HYSTERETIC NON-SYNCHRONOUS PFET BUCK CONTROLLER
| Part | Mounting Type | Function | Package Name | Clock Sync | Voltage - Supply (Vcc/Vdd) Maximum | Voltage - Supply (Vcc/Vdd) Minimum | Package Width | Package Length | Topology | Output Type | Output Configuration | Operating Temperature (Max) | Operating Temperature (Min) | Synchronous Rectifier | Output Phases | Duty Cycle (Max) | Number of Outputs | Qualification | Grade | Total Output Count | Non-Isolated Output Count | Board Type | Supplied Contents | Voltage - Input (Maximum) | Voltage - Input (Minimum) | Main Purpose | Regulator Topology | Current - Output | Voltage - Output | Contents | Utilized IC / Part | Current - Output / Channel | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Surface Mount | Step-Down | 8-TSSOP 8-MSOP 8-VSSOP | No | 35 V | 4.5 V | 3 mm | 0.118 in | Buck | Transistor Driver | Positive | 125 °C | -40 °C | No | 1 | 100 % | 1 | ||||||||||||||||
 Texas Instruments | Surface Mount | Step-Down | 8-TSSOP 8-MSOP 8-VSSOP | No | 35 V | 4.5 V | 3 mm | 0.118 in | Buck | Transistor Driver | Positive | 125 °C | -40 °C | No | 1 | 100 % | 1 | AEC-Q100 | Automotive | ||||||||||||||
 Texas Instruments | Surface Mount | Step-Down | 8-TSSOP 8-MSOP 8-VSSOP | No | 35 V | 4.5 V | 3 mm | 0.118 in | Buck | Transistor Driver | Positive | 125 °C | -40 °C | No | 1 | 100 % | 1 | ||||||||||||||||
 Texas Instruments | Non-Isolated | 1 | 1 count | Fully Populated | Board(s) | 28 V | 7 V | DC/DC Step Down | Buck | 1 A | 3.3 V | Board | LM3485 | ||||||||||||||||||||
Texas Instruments | Surface Mount | Step-Down | 8-TSSOP 8-MSOP 8-VSSOP | No | 35 V | 4.5 V | 3 mm | 0.118 in | Buck | Transistor Driver | Positive | 125 °C | -40 °C | No | 1 | 100 % | 1 | ||||||||||||||||
Texas Instruments | Surface Mount | Step-Down | 8-TSSOP 8-MSOP 8-VSSOP | No | 35 V | 4.5 V | 3 mm | 0.118 in | Buck | Transistor Driver | Positive | 125 °C | -40 °C | No | 1 | 100 % | 1 | ||||||||||||||||
 Texas Instruments | Non-Isolated | 1 | 1 count | Board(s) | 30 V | 5 V | 30 V | Board | LM3485 | 1.4 A | Dimmable |
