LM76 Series

Catalog

SERIAL SWITCH/DIGITAL SENSOR, 13

Part	Test Condition (Max)	Test Condition Temperature	Test Condition (Min)	Operating Temperature (Max)	Operating Temperature (Min)	Features	Mounting Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Resolution	Sensor Type	Package Length	Package Name	Package Width	Sensing Temperature - Local (Min)	Sensing Temperature - Local (Max)	Output Type	Accuracy - Lowest	Accuracy - Highest	Supplied Contents	Utilized IC / Part	Embedded	Contents	Voltage - Supply	Interface	Sensitivity Tolerance	Sensing Range (Max)	Sensing Range (Min)
Texas Instruments LM76CHMX-5	45 °C	25 °C	-10 °C	85 °C	-20 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	12 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-20 °C	85 °C	I2C	1 °C	0.5 °C
Texas Instruments LM76CHM-5	45 °C	25 °C	-10 °C	85 °C	-20 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	12 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-20 °C	85 °C	I2C	1 °C	0.5 °C
Texas Instruments LM76CHM-5/NOPB	45 °C	25 °C	-10 °C	85 °C	-20 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	12 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-20 °C	85 °C	I2C	1 °C	0.5 °C
Texas Instruments LM76CHM-5	45 °C	25 °C	-10 °C	85 °C	-20 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	13 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-20 °C	85 °C	2-Wire Serial I2C SMBus	1 °C	0.5 °C
Texas Instruments LM76CNMX-3	45 °C	25 °C	-10 °C	150 °C	-55 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	12 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-55 °C	150 °C	2-Wire Serial I2C SMBus	1 °C	0.5 °C
Texas Instruments LM76CNM-3	45 °C	25 °C	-10 °C	150 °C	-55 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	12 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-55 °C	150 °C	I2C	1 °C	0.5 °C
Texas Instruments LM76-NEVAL											Temperature									Board(s)	LM76	No	Board	3.3 V	I2C	1 °C	125 °C	-55 °C
Texas Instruments LM76CHMX-5/NOPB	45 °C	25 °C	-10 °C	85 °C	-20 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	12 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-20 °C	85 °C	I2C	1 °C	0.5 °C
Texas Instruments LM76CHMX-5	45 °C	25 °C	-10 °C	85 °C	-20 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	13 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-20 °C	85 °C	2-Wire Serial I2C SMBus	1 °C	0.5 °C
Texas Instruments LM76CHM-5/NOPB	45 °C	25 °C	-10 °C	85 °C	-20 °C	Output Switch Programmable Limit Shutdown Mode	Surface Mount	5.5 V	4.5 V	12 b	Digital Local	0.154 in	8-SOIC	3.9 mm	-20 °C	85 °C	I2C	1 °C	0.5 °C
