TLV742P Series

Catalog

200-MA LOW-IQ LOW-DROPOUT (LDO) VOLTAGE REGULATOR

Part	Output Type	Package / Case	Voltage Dropout (Max)	Package Length	Package Name	Package Width	PSRR (Maximum)	PSRR (Minimum)	Control Features	Output Configuration	Current - Quiescent (Iq)	Operating Temperature (Max)	Operating Temperature (Min)	Current - Output	Protection Features	Number of Regulators	Mounting Type	Voltage - Input (Max)	Voltage - Output (Min/Fixed)
Texas Instruments TLV74233PDQNR	Fixed	4-XDFN Exposed Pad	0.27 V	1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	1	Surface Mount	5.5 V	3.3 V
Texas Instruments TLV74218PDQNR	Fixed	4-XDFN Exposed Pad		1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	1	Surface Mount	5.5 V	1.8 V
Texas Instruments TLV74230PDQNR	Fixed	4-XDFN Exposed Pad	0.27 V	1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature	1	Surface Mount	5.5 V	3 V
Texas Instruments TLV74227PDQNR	Fixed	4-XDFN Exposed Pad	0.3 V	1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	1	Surface Mount	5.5 V	2.7 V
Texas Instruments TLV74211PDQNR	Fixed	4-XDFN Exposed Pad		1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	1	Surface Mount	5.5 V	1.1 V
Texas Instruments TLV74225PDQNR	Fixed	4-XDFN Exposed Pad	0.3 V	1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature	1	Surface Mount	5.5 V	2.5 V
Texas Instruments TLV74215PDQNR	Fixed	4-XDFN Exposed Pad		1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	1	Surface Mount	5.5 V	1.5 V
Texas Instruments TLV74228PDQNR	Fixed	4-XDFN Exposed Pad	0.3 V	1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	1	Surface Mount	5.5 V	2.8 V
Texas Instruments TLV74229PDQNR	Fixed	4-XDFN Exposed Pad	0.27 V	1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	1	Surface Mount	5.5 V	2.9 V
Texas Instruments TLV74212PDQNR	Fixed	4-XDFN Exposed Pad		1 mm	4-X2SON	1 mm	70 dB	55 dB	Enable	Positive	50 µA	125 °C	-40 °C	200 mA	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	1	Surface Mount	5.5 V	1.2 V
