LMH7322 Series

Catalog

BOARD EVALUATION LMH7322

Part	Supplied Contents	Utilized IC / Part	Contents	Function	Type	Output Type	Operating Temperature (Max)	Operating Temperature (Min)	Number of Elements	Package / Case	Current - Output (Typ)	Supply Configuration	Voltage - Supply (Dual) Maximum (Magnitude)	Voltage - Supply (Single) Minimum	Voltage - Supply (Dual) Minimum (Magnitude)	Voltage - Supply (Single) Maximum	Hysteresis	Current - Quiescent (Max)	CMRR (Typ)	PSRR (Typ)	Voltage - Input Offset (Max)	Current - Input Bias (Max)	Mounting Type	Package Length	Package Name	Package Width	Propagation Delay (Max)
Texas Instruments LMH7322EVAL	Board(s)	LMH7322	Board	Comparator	Interface
Texas Instruments LMH7322SQ/NOPB					General Purpose Standard (General Purpose)	Differential LVDS RSPECL	125 °C	-40 °C	2	24-WFQFN Exposed Pad	25 mA	Dual Single	6 V	2.7 V	1.35 V	12 V	75 mV	10 mA	80 dB	80 dB	8 mV	5 µA	Surface Mount	4 mm	24-WQFN	4 mm	0.783 ns
Texas Instruments LMH7322SQX/NOPB					General Purpose Standard (General Purpose)	Differential LVDS RSPECL	125 °C	-40 °C	2	24-WFQFN Exposed Pad	25 mA	Dual Single	6 V	2.7 V	1.35 V	12 V	75 mV	10 mA	80 dB	80 dB	8 mV	5 µA	Surface Mount	4 mm	24-WQFN	4 mm	0.783 ns
Texas Instruments LMH7322SQE/NOPB					General Purpose Standard (General Purpose)	Differential LVDS RSPECL	125 °C	-40 °C	2	24-WFQFN Exposed Pad	25 mA	Dual Single	6 V	2.7 V	1.35 V	12 V	75 mV	10 mA	80 dB	80 dB	8 mV	5 µA	Surface Mount	4 mm	24-WQFN	4 mm	0.783 ns
Texas Instruments LMH7322EVAL/NOPB	Board(s)	LMH7322	Board	Comparator	Interface
